UK Underfloor Heating

We design and supply the highest quality underfloor heating systems and components for your project. Whether you are looking for the best underfloor heating solution for a conservatory, beautifully heated bathroom flooring or you are thinking of installing underfloor heating in a new build house, then our experienced team will help design the perfect package for you.

Our online underfloor heating shop contains everything you need to install a state of the art underfloor heating system in your home. All our products are tested and rated by our team and we only stock products from brands we trust that meet our high standards of quality.

Our underfloor heating price match guarantee gives you the added peace of mind that on top of receiving the highest quality products, you are also getting the best price and value for money.At UK Underfloor Heating we design and build the highest quality underfloor heating kits, deliver them directly to you and offer you all the help and support you need to install your own underfloor heating system.

Under floor heating pipe work is fixed to insulation and concrete is poured over the top. Concrete floor is already in place, insulation is laid on the top of the concrete under floor heating pipe work is then fixed to insulation and screeded over. There are various variations of these methods.

Build a subfloor (min 25mm from top line of joists) between the floor joists using a good quality dense board insulation supported on timber battens fixed to the side of the joist.Then fix the under floor heating pipe work to the insulation, screed the floor flush with the top of the joists. The floor will then require a structural board over once the screed has been allowed to dry.

When installing underfloor heating in a room the maximum length of pipe in one loop is 120 linear metres. Our single area packs come with a minimum of two loops, For underfloor heating packs larger than 24sqm at 200mm centres you will need to install two equal loops. Install approximately 3 to 4 runs (depending on room size) of fixing rail use the insulation clips for the turns and inbetween the fixing rails.

When installing underfloor heating into a full house or ground floor your manifold should ideally be located in a central position so that your pipework doesn't run through rooms it is not going to be heating. You will have instructions showing pipe lengths & pipe centre's for each room some rooms may have more than 1 loop per room dependent on the size (Maximum loop length of 120m).
